HPE Aruba Networking CX 6000 48G Class4 PoE 4SFP 370W

Lifecycle

• Obsolete Date 31-12-2099
• End of support date 31-12-2104

Specifications

• Warranty Limited Lifetime Warranty, see https://www.arubanetworks.com/support-services/ productwarranties/ for warranty and support information included with your product purchase
• Ports 48x ports 10/100/1000BASE-T ports 4x 1G SFP ports
• Latency 1 Gbps: 1.9 μSec
• Switching capacity 104 Gbps
• Input voltage 100-127 VAC / 200-240 VAC
• Power consumption Max Power (w/o PoE): 45W Max Power (w/ PoE): 480W
• Throughput 77.3 Mpps
• Memory and processor Dual Core ARM Cortex A9 @ 1016 Mhz 8 GB DDR3, maximum, depending on model 16 GB eMMC
• Product dimensions (metric) 4.4 x 44.2 x 30.5 cm
• Routing capabilities Static
• Weight 11.07 lbs
• PoE capability 370W Class 4 PoE/PoE+
• Product dimensions (imperial) 1.73 x 17.4 x 12.0 in
• Weight 5.0 kg
• Operating temperature 32°F to 113°F (0°C to 45°C) up to 5000 ft (1.5 km) derate -1°C for every 1000 ft (305 m) from 5000 ft (1.5 km) to 10000 ft (3.0 km)

Quickspecs

• QuickSpecs (PDF)
• QuickSpecs (HTML)
• QuickSpecs
• QuickSpecs

Overview

The HPE Aruba Networking CX 6000 Switch Series is modern family of entry level access switches ideal for branch offices, midsize businesses, and small enterprises. Designed for reliable, simple, and security-enhanced access, the HPE Aruba CX 6000 series provides a convenient and cost-effective wired access solution for networks supporting IoT, mobile, and cloud applications. The HPE Aruba Networking CX 6000 Switch Series is based on the Aruba ASIC architecture with the programmable AOS-CX operating system used across the entire Aruba CX portfolio for a more consistent, more efficient operator experience. This fully-managed series has convenient built-in uplinks with up to 740W of Class 4 PoE to support IoT devices such as security cameras and wireless APs. A compact and fanless model is ideal for use in quiet, small work spaces. The HPE Aruba CX 6000 series is easy to deploy and use with flexible management choices, allowing the best fit for your business and network environment.

What’s new

• HPE Limited Lifetime Warranty and switch software embedded with no subscription required to enable.
• Convenient built-in 1GbE uplinks and up to 740W of Class 4 PoE for support of access points, client, and IoT devices.
• Compact and fanless 12 port PoE model for space-constrained deployments.
• Flexibility to manage with Aruba Central [1], easy to use Web GUI, CLI, or Aruba NetEdit.
• Software defined ready with REST APIs.
• Simplify IT operations with modern Layer 2 Gigabit Ethernet switch series that provides entry level, reliable, and convenient wired access connectivity.

Features

Deploy wireless access points and IoT devices with HPE Aruba Networking CX 6000 switch models that support up to 740W IEEE 802.3at Class 4 Power over Ethernet for up to 30W per port.

Software-defined ready with REST APIs for fine-grained programmability of network tasks.

Reduce manual IT operation tasks around initial deployment or on-going configuration changes to accommodate adds, moves, and changes with colorless ports using local user roles and local-MAC-Authentication (LMA).

Aruba NetEdit introduces automation that allows for rapid network-wide changes, and verifies policy conformance post network updates.

Simplified Configuration and Management

The HPE Aruba Networking CX 6000 Switch Series provides flexibility to manage and simplify configurations with Aruba NetEdit, Aruba Central [1], easy to use Web GUI, or industry standard CLI.

Performance and Power

The HPE Aruba Networking CX 6000 Switch Series offers Ethernet gigabit connectivity and optional PoE to provide entry level, reliable, and convenient wired access connectivity for enterprise branch offices and SMB networks.

Using Aruba AOS-CX operating system across Aruba CX switching platforms and access-to-core-to-data center deployment domains provides a simpler, more consistent operator experience.

Fully-managed enterprise class switches deliver Layer 2 capabilities with support static routing, ACLs, robust QoS, traffic prioritization, sFlow, and IPv6 support.

Simplifies ownership with no switch software licensing or subscriptions required.

Right size deployment with choice of 12, 24, and 48 port 1U models with convenient built-in 1GbE uplinks and up to 740W of Class 4 PoE.

Entry Level Aruba CX Access Layer Switches

Up to four built-in wire speed 1GbE uplinks remove bottlenecks at the access layer where users and devices connect.

The HPE Aruba Networking CX 6000 Switch Series is designed with Aruba ASICs that deliver very low latency, increased packet buffering, and adaptive power consumption.

Media

Switch Forward with Aruba CX Switching for Performance, Scale and High Availability

Free your network from a maze of outdated switching platforms, operating systems, and management tools. Move toward a high-performing, automated, and data-driven future with the Aruba CX Switching Portfolio.

Compatible products

• Aruba 1Y FC NBD Exch 600048G CL4
• HPE Aruba Networking 1G SFP LC SX 500m OM2 MMF Transceiver
• HPE Aruba Networking 1G SFP LC LX 10km SMF Transceiver
• HPE Aruba Networking 1G SFP RJ45 T 100m Cat5e Transceiver
• HPE Aruba Networking X414 1U Universal 4-post Rack Mount Kit
• HPE 2.5M C15 to C14 Pwr Cord
• ARUBA NETEDIT SINGLE NODE 1YR SUB E-STU
• ARUBA NETEDIT SINGLE NODE 3YR SUBSCRIPTI
• Aruba USB-A to USB-C PC-to-Switch Cable
• ARUBA USB-C TO USB-C PC-TO-SWITCH CABLE

Documents

• HPE Aruba Networking CX 6000 Switch Series

[1] Aruba Central support coming in future release.
